Intel Pentium P6100

Intel P6100

O Intel Pentium P6100 é um CPU de nível básico para portáteis. Funciona com uma freqüência de 2 GHz e não suporta TurboBoost para a aceleração automática. Além disso as instruções AES e o hyperthreading estão desabilitados. O CPU suporta Enhanced Speedstep, mas pode haver alguns outros recursos para economizar energia desabilitados (como tinham as séries Penryn - Pentium).

Comparado com o Celeron P4600, o P6100 oferece um desempenho um pouco melhor graças ao System Bus mais veloz e um cache de nível 3 aumentado. Porém, VT-x não está disponível para o P6100.

O P6100 baseia-se nos CPUs Arrandale e, portanto, contém um controlador de memória integrada e placa de vídeo Intel HD Graphics (ambos produzidos em 45nm, o CPU em 32nm). A também chamada de GMA HD no CPU tem uma freqüência de 500MHz e é capaz de acelerar até 766MHz devido ao Turbo Boost (somente GPU).

O desempenho do CPU é um relativamente baixo, devido à baixa freqüência e à falta do Turbo Boost e Hyperthreading. Mesmo assim, o desempenho por GHz deve ser um pouco melhor que o de um Core 2 Duo com freqüência similar, devido ao controlador de memória integrado.

SérieIntel Pentium
CodinomeArrandale

Serie: Pentium Arrandale

Intel Pentium P63002.27 GHz2 / 2 cores3 MB L3
Intel Pentium P62002.13 GHz2 / 2 cores3 MB L3
Intel Pentium P6100 « 2 GHz2 / 2 cores3 MB L3
Intel Pentium P60001.86 GHz2 / 2 cores3 MB L3
Intel Pentium U56001.33 GHz2 / 2 cores3 MB L3
Intel Pentium U54001.2 GHz2 / 2 cores3 MB L3
Frequência2000 MHz
Barramento Frontal2500
Cache de Nível 1128 KB
Cache de Nível 2512 KB
Cache de Nível 33 MB
Número de Núcelos / Subprocessos2 / 2
Consumo de Energia (TDP = Thermal Design Power)35 Watt
Contagem de transistores382+177 Milhão
Tecnologia de Produção32 nm
Tamanho da Matriz81+114 mm2
Tempratura Máx.90 °C
ConectorPGA988
CaracterísticasIntel 64, Enhanced Speedstep, Thermal Monitoring, Execute Disable Bit
64 BitSuporte para 64 Bit
Architecturex86
Data do Anúncio09/26/2010
Link do Produto (externo)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.25     avg: 1.3     median: 1.3 (2%)     max: 1.32 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 2147     avg: 2239     median: 2244.5 (14%)     max: 2280 pontos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 4036     avg: 4319     median: 4355 (3%)     max: 4387 pontos
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 5061     avg: 5368     median: 5396 (3%)     max: 5536 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 1649     avg: 2661     median: 2802.5 (3%)     max: 2869 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 1046     avg: 1083     median: 1073 (13%)     max: 1141 s
wPrime 2.10 - wPrime 2.0 32m *
min: 32.9     avg: 34.4     median: 33.6 (7%)     max: 37.7 s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 1805     avg: 1840     median: 1842.5 (4%)     max: 1865 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 20.9     avg: 21.7     median: 21 (5%)     max: 25 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 49     avg: 50     median: 50 (2%)     max: 52 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 1151     avg: 1297     median: 1168.5 (5%)     max: 1902 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 18345     avg: 18353     median: 18352.5 (9%)     max: 18360 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
13000 MFLOPS (10%)
Windows 7 Experience Index - Win7 CPU
5.7 Points (73%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 4073     avg: 4230     median: 4263.5 (3%)     max: 4320 Points
- Gama de valores benchmark para essa solução gráfica
- Média de valores benchmark para essa solução gráfica
* Smaller numbers mean a higher performance
