Intel Core i7-3540M

Intel 3540M

O Intel Core i7-3540M é o mais veloz processador dual-core para portáteis, baseado na arquitetura Ivy Bridge no momento da introdução no primeiro trimestre de 2013. Graças ao Hyperthreading, os dois núcleos podem suportar até quatro threads em paralelo fazendo uma melhor utilização do CPU. Cada núcleo oferece uma velocidade base de 3,0 GHz, mas pode aumentar a freqüência dinamicamente com Turbo Boost, até 3,5 GHz (para 2 núcleos ativos), e 3,7 GHz (para 1 núcleo ativo). Como o seu predecessor, o Core i7-2640M baseado em Sandy-Bridge, ele oferece um cache de 4 MB L3.

Ivy Bridge é uma matriz aprimorada e reduzida da arquitetura Sandy Bridge com melhorias no desempenho do GPU e CPU. Os CPUs são produzidos em 22nm (contra 32nm dos CPUs Sandy Bridge) e são os primeiros em introduzir transistores 3D para uma maior eficiência energética quando comparado com processadores Sandy Bridge com frequências similares. Outros novos recursos são o PCI Express 3.0 integrado e suporte para DDR3(L)-1600.

O desempenho do Core i7-3540M é ligeiramente superior ao de um processador Sandy Bridge com freqüência similar graças às alterações estruturais. Como resultado, o desempenho está cerca de 5 - 10 % acima do antigo i7-2640M.

O Intel HD Graphics 4000 integrado, oferece 16 Unidades de Execução (EUs) com frequência de 650 MHz até 1300 MHz com Turbo Boost, tornando-o uma das variantes mais rápidas.

Tal como a maioria dos outros dual-cores Ivy Bridge, o i7-3540M está classificado em um TDP de 35 W. Portanto, até mesmo os portáteis menores podem utilizar o Core i7.

SérieIntel Core i7
CodinomeIvy Bridge

Serie: Core i7 Ivy Bridge

Intel Core i7-3940XM3 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-3920XM2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-3840QM2.8 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-3820QM2.7 - 3.7 GHz4 / 8 cores8 MB L3
Intel Core i7-3740QM2.7 - 3.7 GHz4 / 8 cores6 MB L3
Intel Core i7-3720QM2.6 - 3.6 GHz4 / 8 cores6 MB L3
Intel Core i7-3635QM2.4 - 3.4 GHz4 / 8 cores6 MB L3
Intel Core i7-3630QM2.4 - 3.4 GHz4 / 8 cores6 MB L3
Intel Core i7-3615QM2.3 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-3610QM2.3 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-3632QM2.2 - 3.2 GHz4 / 8 cores6 MB L3
Intel Core i7-3612QM2.1 - 3.1 GHz4 / 8 cores6 MB L3
Intel Core i7-3540M « 3 - 3.7 GHz2 / 4 cores4 MB L3
Intel Core i7-3520M2.9 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-3687U2.1 - 3.3 GHz2 / 4 cores4 MB L3
Intel Core i7-3667U2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i7-3537U2 - 3.1 GHz2 / 4 cores4 MB L3
Intel Core i7-3517U1.9 - 3 GHz2 / 4 cores4 MB L3
Intel Core i7-3689Y1.5 - 2.6 GHz2 / 4 cores4 MB L3
Frequência3000 - 3700 MHz
Cache de Nível 1128 KB
Cache de Nível 2512 KB
Cache de Nível 34 MB
Número de Núcelos / Subprocessos2 / 4
Consumo de Energia (TDP = Thermal Design Power)35 Watt
Tecnologia de Produção22 nm
Tempratura Máx.105 °C
ConectorBGA1023, PGA988
CaracterísticasHD Graphics 4000 (650 - 1300 MHz), DDR3-1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 4000 (650 - 1300 MHz)
64 BitSuporte para 64 Bit
Architecturex86
Data do Anúncio01/01/2013
Link do Produto (externo)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 3.41     avg: 3.5     median: 3.5 (4%)     max: 3.49 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 1.52     avg: 1.5     median: 1.5 (36%)     max: 1.54 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 5018     avg: 5030     median: 5029.5 (30%)     max: 5041 pontos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 10628     avg: 10811     median: 10810.5 (8%)     max: 10993 pontos
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 13307     avg: 13435     median: 13434.5 (9%)     max: 13562 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 6326     avg: 6414     median: 6414 (8%)     max: 6502 Points
wPrime 2.10 - wPrime 2.0 1024m *
471.2 s (6%)
wPrime 2.10 - wPrime 2.0 32m *
14.9 s (3%)
WinRAR - WinRAR 4.0
2940 pontos (5%)
X264 HD Benchmark 4.0 - x264 Pass 2
19.9 fps (7%)
X264 HD Benchmark 4.0 - x264 Pass 1
105.3 fps (24%)
TrueCrypt - TrueCrypt Serpent
0.2 GB/s (5%)
TrueCrypt - TrueCrypt Twofish
0.3 GB/s (5%)
TrueCrypt - TrueCrypt AES
1.7 GB/s (4%)
3DMark 06 - CPU - 3DMark 06 - CPU
min: 4267     avg: 4320     median: 4319.5 (9%)     max: 4372 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
10.4 s (2%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
23.9 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
557 s (2%)
Windows 7 Experience Index - Win7 CPU
7.3 Points (94%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
11749 Points (9%)
3DMark 11 - 3DM11 Performance Physics
min: 4391     avg: 4627     median: 4627 (12%)     max: 4863 Points
3DMark - 3DMark Ice Storm Physics
min: 40631     avg: 42023     median: 42022.5 (34%)     max: 43414 Points
3DMark - 3DMark Cloud Gate Physics
min: 3424     avg: 3483     median: 3482.5 (9%)     max: 3541 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 4929     avg: 4966     median: 4966 (9%)     max: 5003 Points
- Gama de valores benchmark para essa solução gráfica
- Média de valores benchmark para essa solução gráfica
* Smaller numbers mean a higher performance
