Breve Análise do Huawei MateBook 13 (2020) - Um portátil Ryzen nem sempre é a melhor opção

Comparativamente compacto e ainda mais barato do que a versão Intel, o MateBook 13 se apresenta configurado com um chipset AMD. Nossa análise esclarecerá, no entanto, quem estaria melhor se investisse um pouco mais de dinheiro.
Huawei MateBook 13 2020 AMD (MateBook Serie)
Processador
AMD Ryzen 5 3500U 4 x 2.1 - 3.7 GHz, Picasso-U (Zen+)
Placa gráfica
AMD Radeon RX Vega 8 (Ryzen 2000/3000)
Memória
8 GB
, Samsung, LPDDR4, 2400 MHz
Pantalha
13.00 polegadas 3:2, 2160 x 1440 pixel 200 PPI, Chi Mei CMN8201 P130ZFA-BA1, IPS, Brilhante: sim, 60 Hz
placa mãe
AMD Promontory/Bixby FCH
Disco rígido
WDC PC SN730 SDBPNTY-512G, 512 GB
, 422.2 GB livre
Placa de Som
AMD Rave/Renoir - Audio Processor - HD Audio Controller
Conexões
2 USB 3.0, 1 DisplayPort, Conexões Audio: Conector combinado para fones e microfone (de 3,5 mm), 1 Leitor de Impressões Digitais, NFC, Brightness Sensor, Sensores: Sensor de calor e hall
Funcionamento em rede
Realtek 8822CE Wireless LAN 802.11ac PCI-E NIC (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 5.0
Tamanho
altura x largura x profundidade (em mm): 14.9 x 286 x 211
Bateria
41.7 Wh, 3660 mAh Lítio-Polímero, 11,4 V, Duração da bateria (de acordo com o fabricante): 7.5 h
Sistema Operativo
Microsoft Windows 10 Home 64 Bit
Camera
Primary Camera: 1 MPix
Características adicionais
Alto falantes: Estéreo, Teclado: chiclet, Iluminação do Teclado: sim, 65-watt power adapter (USB Type-C), USB cable, USB-C to USB-A adapter, quick-start guide, 24 Meses Garantia, Huawei Share, PC Manager
peso
1.317 kg, Suprimento de energia: 198 g
Preço
799 Euro
Note: The manufacturer may use components from different suppliers including display panels, drives or memory sticks with similar specifications.



Rating
Date
Model
Weight
Height
Size
Resolution
Price
84 %
v7 (old)
07/2020
Huawei MateBook 13 2020 AMD
R5 3500U, Vega 8
1.3 kg14.9 mm13.00"2160x1440
84.4 %
v7 (old)
06/2020
Huawei MateBook 13 2020 i5
i5-10210U, UHD Graphics 620
1.3 kg14.9 mm13.00"2160x1440
88 %
v7 (old)
04/2020
Apple MacBook Air 2020 i5
i5-1030NG7, Iris Plus Graphics G7 (Ice Lake 64 EU)
1.3 kg16.1 mm13.30"2560x1600
88.8 %
v7 (old)
03/2020
Dell XPS 13 9300 i5 FHD
i5-1035G1, UHD Graphics G1 (Ice Lake 32 EU)
1.2 kg14.8 mm13.40"1920x1200
85.9 %
v7 (old)
09/2020
Acer Swift 3 SF313-52-52AS
i5-1035G4, Iris Plus Graphics G4 (Ice Lake 48 EU)
1.2 kg16.6 mm13.50"2256x1504
Networking
iperf3 transmit AX12
Dell XPS 13 9300 i5 FHD
Intel Killer Wi-Fi 6 AX1650s
906 MBit/s +36%
Huawei MateBook 13 2020 i5
Intel Wireless-AC 9560
708 (684min - 720max) MBit/s +6%
Acer Swift 3 SF313-52-52AS
Intel Wi-Fi 6 AX201
696 (679min - 711max) MBit/s +5%
Huawei MateBook 13 2020 AMD
Realtek 8822CE Wireless LAN 802.11ac PCI-E NIC
666 (328min - 692max) MBit/s
Average Realtek 8822CE Wireless LAN 802.11ac PCI-E NIC
  (87 - 690, n=29)
618 MBit/s -7%
Apple MacBook Air 2020 i5
802.11 a/b/g/n/ac
550 (546min - 561max) MBit/s -17%
iperf3 receive AX12
Dell XPS 13 9300 i5 FHD
Intel Killer Wi-Fi 6 AX1650s
1460 MBit/s +124%
Acer Swift 3 SF313-52-52AS
Intel Wi-Fi 6 AX201
870 (832min - 928max) MBit/s +33%
Huawei MateBook 13 2020 AMD
Realtek 8822CE Wireless LAN 802.11ac PCI-E NIC
652 (639min - 661max) MBit/s
Huawei MateBook 13 2020 i5
Intel Wireless-AC 9560
627 (579min - 673max) MBit/s -4%
Average Realtek 8822CE Wireless LAN 802.11ac PCI-E NIC
  (486 - 685, n=29)
622 MBit/s -5%
Apple MacBook Air 2020 i5
802.11 a/b/g/n/ac
612 (576min - 636max) MBit/s -6%
04080120160200240280320360400440480520560600640680Tooltip
Huawei MateBook 13 2020 AMD; iperf3 receive AX12; iperf 3.1.3: Ø652 (639-661)
Huawei MateBook 13 2020 AMD; iperf3 transmit AX12; iperf 3.1.3: Ø656 (328-692)
03570105140175210245280315350385420455490525560595630665Tooltip
Huawei MateBook 13 2020 AMD AMD Ryzen 5 3500U, AMD Ryzen 5 3500U: Ø571 (564.95-646.42)
Huawei MateBook 13 2020 i5 Intel Core i5-10210U, Intel Core i5-10210U: Ø530 (520.93-665.09)
Apple MacBook Air 2020 i5 Intel Core i5-1030NG7, Intel Core i5-1030NG7; macOS 10.15: Ø401 (363.09-448.1)
HP EliteBook 735 G6 7KN29EA AMD Ryzen 5 PRO 3500U, AMD Ryzen 5 PRO 3500U: Ø561 (547.56-636.74)
Cinebench R20: CPU (Single Core) | CPU (Multi Core)
Cinebench R15: CPU Single 64Bit | CPU Multi 64Bit
Blender: v2.79 BMW27 CPU
7-Zip 18.03: 7z b 4 -mmt1 | 7z b 4
Geekbench 5.5: Single-Core | Multi-Core
HWBOT x265 Benchmark v2.2: 4k Preset
LibreOffice : 20 Documents To PDF
R Benchmark 2.5: Overall mean
Cinebench R20 / CPU (Single Core)
Average of class Subnotebook
  (128 - 790, n=57, last 2 years)
636 Points +72%
Dell XPS 13 9300 i5 FHD
Intel Core i5-1035G1
425 Points +15%
Huawei MateBook 13 2020 i5
Intel Core i5-10210U
421 Points +14%
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
375 Points +1%
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
330 Points -11%
Huawei MateBook 13 2020 AMD
AMD Ryzen 5 3500U
370 Points
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
357 Points -4%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
357 Points -4%
HP EliteBook 735 G6 7KN29EA
AMD Ryzen 5 PRO 3500U
354 Points -4%
Average AMD Ryzen 5 3500U
  (317 - 372, n=15)
354 Points -4%
Cinebench R20 / CPU (Multi Core)
Average of class Subnotebook
  (579 - 8541, n=57, last 2 years)
4548 Points +236%
Dell XPS 13 9300 i5 FHD
Intel Core i5-1035G1
1533 Points +13%
Average AMD Ryzen 5 3500U
  (1063 - 1540, n=15)
1436 Points +6%
Huawei MateBook 13 2020 AMD
AMD Ryzen 5 3500U
1355 Points
HP EliteBook 735 G6 7KN29EA
AMD Ryzen 5 PRO 3500U
1328 Points -2%
Huawei MateBook 13 2020 i5
Intel Core i5-10210U
1325 Points -2%
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
987 Points -27%
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
764 Points -44%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
892 Points -34%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
892 Points -34%
Cinebench R15 / CPU Single 64Bit
Average of class Subnotebook
  (72.4 - 307, n=58, last 2 years)
249 Points +72%
Huawei MateBook 13 2020 i5
Intel Core i5-10210U
168 Points +16%
Dell XPS 13 9300 i5 FHD
Intel Core i5-1035G1
166 Points +15%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
146.4 Points +1%
Huawei MateBook 13 2020 AMD
AMD Ryzen 5 3500U
144.5 Points
Average AMD Ryzen 5 3500U
  (131 - 147, n=18)
142.4 Points -1%
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
140 Points -3%
HP EliteBook 735 G6 7KN29EA
AMD Ryzen 5 PRO 3500U
140 Points -3%
Cinebench R15 / CPU Multi 64Bit
Average of class Subnotebook
  (327 - 3345, n=63, last 2 years)
1987 Points +208%
Dell XPS 13 9300 i5 FHD
Intel Core i5-1035G1
667 Points +3%
Dell XPS 13 9300 i5 FHD
Intel Core i5-1035G1
659 Points +2%
Huawei MateBook 13 2020 i5
Intel Core i5-10210U
665 (520.93min - 665.09max) Points +3%
Huawei MateBook 13 2020 AMD
AMD Ryzen 5 3500U
646 (564.95min - 646.42max) Points
Average AMD Ryzen 5 3500U
  (482 - 682, n=19)
642 Points -1%
HP EliteBook 735 G6 7KN29EA
AMD Ryzen 5 PRO 3500U
637 (547.56min - 636.74max) Points -1%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
490.1 (289.98min - 451.62max) Points -24%
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
448 (363min - 448max) Points -31%
Blender / v2.79 BMW27 CPU
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
1310 Seconds * -65%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
1016 Seconds * -28%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
1016 Seconds * -28%
Huawei MateBook 13 2020 i5
Intel Core i5-10210U
826 Seconds * -4%
HP EliteBook 735 G6 7KN29EA
AMD Ryzen 5 PRO 3500U
805 Seconds * -1%
Huawei MateBook 13 2020 AMD
AMD Ryzen 5 3500U
796 Seconds *
Dell XPS 13 9300 i5 FHD
Intel Core i5-1035G1
766 Seconds * +4%
Average AMD Ryzen 5 3500U
  (680 - 796, n=10)
704 Seconds * +12%
Average of class Subnotebook
  (159 - 2271, n=61, last 2 years)
359 Seconds * +55%
7-Zip 18.03 / 7z b 4 -mmt1
Average of class Subnotebook
  (2669 - 6403, n=56, last 2 years)
5486 MIPS +57%
Huawei MateBook 13 2020 i5
Intel Core i5-10210U
4324 MIPS +23%
Dell XPS 13 9300 i5 FHD
Intel Core i5-1035G1
4087 MIPS +17%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
4048 MIPS +16%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
4048 MIPS +16%
Average AMD Ryzen 5 3500U
  (3502 - 3580, n=10)
3541 MIPS +1%
Huawei MateBook 13 2020 AMD
AMD Ryzen 5 3500U
3502 MIPS
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
3472 MIPS -1%
HP EliteBook 735 G6 7KN29EA
AMD Ryzen 5 PRO 3500U
3432 MIPS -2%
7-Zip 18.03 / 7z b 4
Average of class Subnotebook
  (11775 - 77867, n=54, last 2 years)
48778 MIPS +208%
Dell XPS 13 9300 i5 FHD
Intel Core i5-1035G1
18535 MIPS +17%
Average AMD Ryzen 5 3500U
  (15825 - 17508, n=10)
16929 MIPS +7%
Huawei MateBook 13 2020 i5
Intel Core i5-10210U
16685 MIPS +5%
HP EliteBook 735 G6 7KN29EA
AMD Ryzen 5 PRO 3500U
15910 MIPS +1%
Huawei MateBook 13 2020 AMD
AMD Ryzen 5 3500U
15825 MIPS
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
13057 MIPS -17%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
13057 MIPS -17%
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
10924 MIPS -31%
Geekbench 5.5 / Single-Core
Average of class Subnotebook
  (621 - 2350, n=57, last 2 years)
1783 Points +99%
Dell XPS 13 9300 i5 FHD
Intel Core i5-1035G1
1229 Points +37%
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
1167 Points +31%
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
1010 Points +13%
Huawei MateBook 13 2020 i5
Intel Core i5-10210U
1094 Points +22%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
1081 Points +21%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
1081 Points +21%
Huawei MateBook 13 2020 AMD
AMD Ryzen 5 3500U
894 Points
Average AMD Ryzen 5 3500U
  (777 - 909, n=9)
886 Points -1%
HP EliteBook 735 G6 7KN29EA
AMD Ryzen 5 PRO 3500U
863 Points -3%
Geekbench 5.5 / Multi-Core
Average of class Subnotebook
  (2557 - 14728, n=57, last 2 years)
10113 Points +229%
Dell XPS 13 9300 i5 FHD
Intel Core i5-1035G1
4372 Points +42%
Huawei MateBook 13 2020 i5
Intel Core i5-10210U
4119 Points +34%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
3261 Points +6%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
3261 Points +6%
Average AMD Ryzen 5 3500U
  (2543 - 3269, n=9)
3097 Points +1%
Huawei MateBook 13 2020 AMD
AMD Ryzen 5 3500U
3076 Points
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
2881 Points -6%
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
2539 Points -17%
HP EliteBook 735 G6 7KN29EA
AMD Ryzen 5 PRO 3500U
2824 Points -8%
HWBOT x265 Benchmark v2.2 / 4k Preset
Average of class Subnotebook
  (0.97 - 25.1, n=56, last 2 years)
13 fps +288%
Huawei MateBook 13 2020 i5
Intel Core i5-10210U
4.37 fps +30%
Dell XPS 13 9300 i5 FHD
Intel Core i5-1035G1
4.27 fps +27%
Average AMD Ryzen 5 3500U
  (3.35 - 4.15, n=10)
3.94 fps +18%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
3.37 fps +1%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
3.37 fps +1%
HP EliteBook 735 G6 7KN29EA
AMD Ryzen 5 PRO 3500U
3.36 fps 0%
Huawei MateBook 13 2020 AMD
AMD Ryzen 5 3500U
3.35 fps
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
2.95 fps -12%
LibreOffice / 20 Documents To PDF
HP EliteBook 735 G6 7KN29EA
AMD Ryzen 5 PRO 3500U
117 s * -28%
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
110 s * -20%
Huawei MateBook 13 2020 AMD
AMD Ryzen 5 3500U
91.4 s *
Average AMD Ryzen 5 3500U
  (81.9 - 91.4, n=3)
86.5 s * +5%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
78.3 s * +14%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
78.3 s * +14%
Huawei MateBook 13 2020 i5
Intel Core i5-10210U
58.7 s * +36%
Average of class Subnotebook
  (38.5 - 220, n=56, last 2 years)
54.7 s * +40%
R Benchmark 2.5 / Overall mean
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
0.922 sec * -15%
Apple MacBook Air 2020 i5
Intel Core i5-1030NG7
0.909 sec * -13%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
0.825 sec * -3%
Acer Swift 3 SF313-52-52AS
Intel Core i5-1035G4
0.825 sec * -3%
Huawei MateBook 13 2020 AMD
AMD Ryzen 5 3500U
0.804 sec *
HP EliteBook 735 G6 7KN29EA
AMD Ryzen 5 PRO 3500U
0.77 sec * +4%
Average AMD Ryzen 5 3500U
  (0.734 - 0.804, n=8)
0.749 sec * +7%
Dell XPS 13 9300 i5 FHD
Intel Core i5-1035G1
0.722 sec * +10%
Huawei MateBook 13 2020 i5
Intel Core i5-10210U
0.713 sec * +11%
Average of class Subnotebook
  (0.413 - 1.456, n=56, last 2 years)
0.518 sec * +36%

* ... smaller is better

Cinebench R15 CPU Single 64Bit
144.5 Points
Cinebench R15 CPU Multi 64Bit
646 Points
Cinebench R15 OpenGL 64Bit
49.16 fps
Cinebench R15 Ref. Match 64Bit
98 %
Cinebench R20 CPU (Multi Core)
1355 Points
Cinebench R20 CPU (Single Core)
370 Points
Ajuda
PCMark 10
Score
Average of class Subnotebook
  (4993 - 7788, n=49, last 2 years)
6427 Points +66%
Dell XPS 13 9300 i5 FHD
UHD Graphics G1 (Ice Lake 32 EU), i5-1035G1, Toshiba XG6 KXG60ZNV512G
4122 Points +7%
Huawei MateBook 13 2020 i5
UHD Graphics 620, i5-10210U, WDC PC SN730 SDBPNTY-512G
4067 Points +5%
Huawei MateBook 13 2020 AMD
Vega 8, R5 3500U, WDC PC SN730 SDBPNTY-512G
3861 Points
Acer Swift 3 SF313-52-52AS
Iris Plus Graphics G4 (Ice Lake 48 EU), i5-1035G4, SK Hynix BC501 HFM512GDJTNG
3790 Points -2%
Average AMD Ryzen 5 3500U, AMD Radeon RX Vega 8 (Ryzen 2000/3000)
  (3485 - 3972, n=16)
3766 Points -2%
HP EliteBook 735 G6 7KN29EA
Vega 8, R5 PRO 3500U, WDC PC SN520 SDAPNUW-256G
3389 Points -12%
Apple MacBook Air 2020 i5
Iris Plus Graphics G7 (Ice Lake 64 EU), i5-1030NG7, Apple SSD AP0512
2540 Points -34%
Essentials
Average of class Subnotebook
  (9476 - 11331, n=49, last 2 years)
10486 Points +39%
Huawei MateBook 13 2020 i5
UHD Graphics 620, i5-10210U, WDC PC SN730 SDBPNTY-512G
8715 Points +15%
Dell XPS 13 9300 i5 FHD
UHD Graphics G1 (Ice Lake 32 EU), i5-1035G1, Toshiba XG6 KXG60ZNV512G
8568 Points +14%
Acer Swift 3 SF313-52-52AS
Iris Plus Graphics G4 (Ice Lake 48 EU), i5-1035G4, SK Hynix BC501 HFM512GDJTNG
7558 Points 0%
Huawei MateBook 13 2020 AMD
Vega 8, R5 3500U, WDC PC SN730 SDBPNTY-512G
7548 Points
Average AMD Ryzen 5 3500U, AMD Radeon RX Vega 8 (Ryzen 2000/3000)
  (6690 - 8300, n=16)
7533 Points 0%
Apple MacBook Air 2020 i5
Iris Plus Graphics G7 (Ice Lake 64 EU), i5-1030NG7, Apple SSD AP0512
6746 Points -11%
HP EliteBook 735 G6 7KN29EA
Vega 8, R5 PRO 3500U, WDC PC SN520 SDAPNUW-256G
6563 Points -13%
Productivity
Average of class Subnotebook
  (6440 - 10623, n=49, last 2 years)
8627 Points +46%
Dell XPS 13 9300 i5 FHD
UHD Graphics G1 (Ice Lake 32 EU), i5-1035G1, Toshiba XG6 KXG60ZNV512G
6766 Points +15%
Huawei MateBook 13 2020 i5
UHD Graphics 620, i5-10210U, WDC PC SN730 SDBPNTY-512G
6720 Points +14%
Acer Swift 3 SF313-52-52AS
Iris Plus Graphics G4 (Ice Lake 48 EU), i5-1035G4, SK Hynix BC501 HFM512GDJTNG
6414 Points +9%
Huawei MateBook 13 2020 AMD
Vega 8, R5 3500U, WDC PC SN730 SDBPNTY-512G
5900 Points
Average AMD Ryzen 5 3500U, AMD Radeon RX Vega 8 (Ryzen 2000/3000)
  (5456 - 6074, n=16)
5774 Points -2%
HP EliteBook 735 G6 7KN29EA
Vega 8, R5 PRO 3500U, WDC PC SN520 SDAPNUW-256G
5264 Points -11%
Apple MacBook Air 2020 i5
Iris Plus Graphics G7 (Ice Lake 64 EU), i5-1030NG7, Apple SSD AP0512
3033 Points -49%
Digital Content Creation
Average of class Subnotebook
  (5305 - 10983, n=49, last 2 years)
8048 Points +129%
Huawei MateBook 13 2020 AMD
Vega 8, R5 3500U, WDC PC SN730 SDBPNTY-512G
3509 Points
Average AMD Ryzen 5 3500U, AMD Radeon RX Vega 8 (Ryzen 2000/3000)
  (2989 - 3526, n=16)
3337 Points -5%
Dell XPS 13 9300 i5 FHD
UHD Graphics G1 (Ice Lake 32 EU), i5-1035G1, Toshiba XG6 KXG60ZNV512G
3281 Points -6%
Huawei MateBook 13 2020 i5
UHD Graphics 620, i5-10210U, WDC PC SN730 SDBPNTY-512G
3118 Points -11%
HP EliteBook 735 G6 7KN29EA
Vega 8, R5 PRO 3500U, WDC PC SN520 SDAPNUW-256G
3061 Points -13%
Acer Swift 3 SF313-52-52AS
Iris Plus Graphics G4 (Ice Lake 48 EU), i5-1035G4, SK Hynix BC501 HFM512GDJTNG
3048 Points -13%
Apple MacBook Air 2020 i5
Iris Plus Graphics G7 (Ice Lake 64 EU), i5-1030NG7, Apple SSD AP0512
2174 Points -38%
PCMark 8
Home Score Accelerated v2
Dell XPS 13 9300 i5 FHD
UHD Graphics G1 (Ice Lake 32 EU), i5-1035G1, Toshiba XG6 KXG60ZNV512G
3988 Points +4%
Huawei MateBook 13 2020 i5
UHD Graphics 620, i5-10210U, WDC PC SN730 SDBPNTY-512G
3946 Points +3%
Huawei MateBook 13 2020 AMD
Vega 8, R5 3500U, WDC PC SN730 SDBPNTY-512G
3846 Points
Average AMD Ryzen 5 3500U, AMD Radeon RX Vega 8 (Ryzen 2000/3000)
  (3316 - 4235, n=13)
3600 Points -6%
HP EliteBook 735 G6 7KN29EA
Vega 8, R5 PRO 3500U, WDC PC SN520 SDAPNUW-256G
3311 Points -14%
Average of class Subnotebook
  (1739 - 4730, n=2, last 2 years)
3235 Points -16%
Work Score Accelerated v2
Dell XPS 13 9300 i5 FHD
UHD Graphics G1 (Ice Lake 32 EU), i5-1035G1, Toshiba XG6 KXG60ZNV512G
4832 Points +9%
Huawei MateBook 13 2020 i5
UHD Graphics 620, i5-10210U, WDC PC SN730 SDBPNTY-512G
4773 Points +8%
Average AMD Ryzen 5 3500U, AMD Radeon RX Vega 8 (Ryzen 2000/3000)
  (4436 - 5039, n=12)
4707 Points +6%
HP EliteBook 735 G6 7KN29EA
Vega 8, R5 PRO 3500U, WDC PC SN520 SDAPNUW-256G
4558 Points +3%
Huawei MateBook 13 2020 AMD
Vega 8, R5 3500U, WDC PC SN730 SDBPNTY-512G
4436 Points
Average of class Subnotebook
  (1609 - 5271, n=2, last 2 years)
3440 Points -22%
PCMark 8 Home Score Accelerated v2
3846 pontos
PCMark 8 Creative Score Accelerated v2
4845 pontos
PCMark 8 Work Score Accelerated v2
4436 pontos
PCMark 10 Score
3861 pontos
Ajuda
DPC Latencies / LatencyMon - interrupt to process latency (max), Web, Youtube, Prime95
Apple MacBook Air 2020 i5
Iris Plus Graphics G7 (Ice Lake 64 EU), i5-1030NG7, Apple SSD AP0512
2635 μs * -165%
Acer Swift 3 SF313-52-52AS
Iris Plus Graphics G4 (Ice Lake 48 EU), i5-1035G4, SK Hynix BC501 HFM512GDJTNG
1997 μs * -101%
HP EliteBook 735 G6 7KN29EA
Vega 8, R5 PRO 3500U, WDC PC SN520 SDAPNUW-256G
1497 μs * -51%
Dell XPS 13 9300 i5 FHD
UHD Graphics G1 (Ice Lake 32 EU), i5-1035G1, Toshiba XG6 KXG60ZNV512G
1368 μs * -38%
Huawei MateBook 13 2020 i5
UHD Graphics 620, i5-10210U, WDC PC SN730 SDBPNTY-512G
1135 μs * -14%
Huawei MateBook 13 2020 AMD
Vega 8, R5 3500U, WDC PC SN730 SDBPNTY-512G
993 μs *

* ... smaller is better

Huawei MateBook 13 2020 AMD
WDC PC SN730 SDBPNTY-512G
Huawei MateBook 13 2020 i5
WDC PC SN730 SDBPNTY-512G
Apple MacBook Air 2020 i5
Apple SSD AP0512
Dell XPS 13 9300 i5 FHD
Toshiba XG6 KXG60ZNV512G
Acer Swift 3 SF313-52-52AS
SK Hynix BC501 HFM512GDJTNG
Average WDC PC SN730 SDBPNTY-512G

CrystalDiskMark 5.2 / 6
18%
15%
-10%
33%
Write 4K
143.9
190.5
32%
121.9
-15%
120.6
-16%
164.3 ?(106.9 - 242, n=21)
14%
Read 4K
45.91
53.7
17%
50
9%
46.88
2%
Write Seq
1307
1436
10%
1497
15%
1044
-20%
Read Seq
1435
1356
-6%
2111
47%
1147
-20%
Write 4K Q32T1
237.1
382.5
61%
365.9
54%
332.4
40%
Read 4K Q32T1
332.7
502
51%
384.6
16%
443.3
33%
Write Seq Q32T1
2698
2114
-22%
2748
2%
1052
-61%
Read Seq Q32T1
3394
3410
0%
3119
-8%
2171
-36%
AS SSD
65%
-64%
-9%
-25%
39%
Seq Read
2844
2912
2%
1153
-59%
2328
-18%
1370
-52%
Seq Write
2316
2190
-5%
1367
-41%
1137
-51%
1019
-56%
1905 ?(993 - 2486, n=21)
-18%
4K Read
40.76
49.52
21%
12.95
-68%
48.07
18%
50.8
25%
4K Write
96.9
167.1
72%
24.52
-75%
120.6
24%
111.2
15%
155.6 ?(96.9 - 217, n=21)
61%
4K-64 Read
1275
1447
13%
665
-48%
899
-29%
770
-40%
4K-64 Write
1156
1513
31%
159.5
-86%
1220
6%
713
-38%
Access Time Read *
0.074
0.05
32%
0.295
-299%
0.085
-15%
0.0801 ?(0.05 - 0.138, n=21)
-8%
Access Time Write *
0.039
0.023
41%
0.163
-318%
0.033
15%
0.034
13%
0.04195 ?(0.018 - 0.091, n=21)
-8%
Score Read
1600
1787
12%
793
-50%
1180
-26%
958
-40%
Score Write
1485
1899
28%
321
-78%
1455
-2%
926
-38%
Score Total
3879
4569
18%
1528
-61%
3189
-18%
2370
-39%
Copy ISO MB/s
433.2
2290
429%
1433
231%
1718 ?(433 - 3092, n=13)
297%
Copy Program MB/s
266.4
555
108%
363
36%
536 ?(257 - 790, n=13)
101%
Copy Game MB/s
620
1300
110%
725
17%
Total Average (Program / Settings)
42% / 48%
-64% / -64%
3% / 1%
-18% / -18%
36% / 37%

* ... smaller is better

WDC PC SN730 SDBPNTY-512G
CDM 5/6 Read Seq Q32T1: 3394 MB/s
CDM 5/6 Write Seq Q32T1: 2698 MB/s
CDM 5/6 Read 4K Q32T1: 332.7 MB/s
CDM 5/6 Write 4K Q32T1: 237.1 MB/s
CDM 5 Read Seq: 1435 MB/s
CDM 5 Write Seq: 1307 MB/s
CDM 5/6 Read 4K: 45.91 MB/s
CDM 5/6 Write 4K: 143.9 MB/s

Continuous load read: DiskSpd Read Loop, Queue Depth 8

No graph data
3DMark 11 - 1280x720 Performance GPU
Average of class Subnotebook
  (968 - 16296, n=53, last 2 years)
9600 Points +175%
Huawei MateBook 13 2020 AMD
AMD Radeon RX Vega 8 (Ryzen 2000/3000), AMD Ryzen 5 3500U
3486 Points
Average AMD Radeon RX Vega 8 (Ryzen 2000/3000)
  (1668 - 4317, n=44)
3447 Points -1%
HP EliteBook 735 G6 7KN29EA
AMD Radeon RX Vega 8 (Ryzen 2000/3000), AMD Ryzen 5 PRO 3500U
2997 Points -14%
Apple MacBook Air 2020 i5
Intel Iris Plus Graphics G7 (Ice Lake 64 EU), Intel Core i5-1030NG7
2924 Points -16%
Acer Swift 3 SF313-52-52AS
Intel Iris Plus Graphics G4 (Ice Lake 48 EU), Intel Core i5-1035G4
2809 Points -19%
Dell XPS 13 9300 i5 FHD
Intel UHD Graphics G1 (Ice Lake 32 EU), Intel Core i5-1035G1
2578 Points -26%
Huawei MateBook 13 2020 i5
Intel UHD Graphics 620, Intel Core i5-10210U
1852 Points -47%
3DMark
1280x720 Cloud Gate Standard Graphics
Average of class Subnotebook
  (5577 - 58319, n=29, last 2 years)
36827 Points +101%
Huawei MateBook 13 2020 AMD
AMD Radeon RX Vega 8 (Ryzen 2000/3000), AMD Ryzen 5 3500U
18329 Points
Average AMD Radeon RX Vega 8 (Ryzen 2000/3000)
  (7309 - 19399, n=37)
15327 Points -16%
Dell XPS 13 9300 i5 FHD
Intel UHD Graphics G1 (Ice Lake 32 EU), Intel Core i5-1035G1
12698 Points -31%
HP EliteBook 735 G6 7KN29EA
AMD Radeon RX Vega 8 (Ryzen 2000/3000), AMD Ryzen 5 PRO 3500U
12233 Points -33%
Huawei MateBook 13 2020 i5
Intel UHD Graphics 620, Intel Core i5-10210U
10111 Points -45%
1920x1080 Fire Strike Graphics
Average of class Subnotebook
  (832 - 11887, n=57, last 2 years)
6933 Points +197%
Huawei MateBook 13 2020 AMD
AMD Radeon RX Vega 8 (Ryzen 2000/3000), AMD Ryzen 5 3500U
2335 Points
Average AMD Radeon RX Vega 8 (Ryzen 2000/3000)
  (1095 - 2901, n=41)
2224 Points -5%
Acer Swift 3 SF313-52-52AS
Intel Iris Plus Graphics G4 (Ice Lake 48 EU), Intel Core i5-1035G4
1995 Points -15%
HP EliteBook 735 G6 7KN29EA
AMD Radeon RX Vega 8 (Ryzen 2000/3000), AMD Ryzen 5 PRO 3500U
1872 Points -20%
Apple MacBook Air 2020 i5
Intel Iris Plus Graphics G7 (Ice Lake 64 EU), Intel Core i5-1030NG7
1846 Points -21%
Dell XPS 13 9300 i5 FHD
Intel UHD Graphics G1 (Ice Lake 32 EU), Intel Core i5-1035G1
1755 Points -25%
Huawei MateBook 13 2020 i5
Intel UHD Graphics 620, Intel Core i5-10210U
1280 Points -45%
2560x1440 Time Spy Graphics
Average of class Subnotebook
  (999 - 4501, n=58, last 2 years)
2547 Points +222%
Huawei MateBook 13 2020 AMD
AMD Radeon RX Vega 8 (Ryzen 2000/3000), AMD Ryzen 5 3500U
790 Points
Average AMD Radeon RX Vega 8 (Ryzen 2000/3000)
  (523 - 790, n=23)
673 Points -15%
HP EliteBook 735 G6 7KN29EA
AMD Radeon RX Vega 8 (Ryzen 2000/3000), AMD Ryzen 5 PRO 3500U
568 Points -28%
Apple MacBook Air 2020 i5
Intel Iris Plus Graphics G7 (Ice Lake 64 EU), Intel Core i5-1030NG7
526 Points -33%
Dell XPS 13 9300 i5 FHD
Intel UHD Graphics G1 (Ice Lake 32 EU), Intel Core i5-1035G1
472 Points -40%
3DMark 11 Performance
3619 pontos
3DMark Cloud Gate Standard Score
13533 pontos
3DMark Fire Strike Score
2142 pontos
3DMark Fire Strike Extreme Score
979 pontos
3DMark Time Spy Score
881 pontos
Ajuda
baixomédiaaltoultra
The Witcher 3 (2015) 24.5 15.35
Dota 2 Reborn (2015) 70 63.2 38.9 34.6
Warhammer 40.000: Dawn of War III (2017) 42.69 17.95
X-Plane 11.11 (2018) 26.9 21 18.4
Far Cry 5 (2018) 19 12
F1 2019 (2019) 46.2 27.6 24.2 22.5

Barulho

Ocioso
27.2 / 27.2 / 27.2 dB
Carga
31.8 / 38.3 dB
  red to green bar


30 dB
silencioso
40 dB(A)
audível
50 dB(A)
ruidosamente alto

min: dark, med: mid, max: light   Audix TM1, Arta (15 cm de distância)   environment noise: 27.2 dB(A)
dB(A) 0102030405060708090Deep BassMiddle BassHigh BassLower RangeMidsHigher MidsLower HighsMid HighsUpper HighsSuper Highs2038.732.937.231.738.7253433.334.128.7343130.627.52830.630.64025.727.424.523.725.75029353130.7296326.730.728.523.826.78023.523.927.224.223.510025.520.925.724.625.512522.11821.120.522.116020.220.321.218.320.220023.320.119.818.723.325021.420.717.816.621.431521.520.618.71721.540022.117.717.314.722.150023.818.815.31423.863025.518.51515.225.580024.217.714.314.224.2100023.921.415.214.623.9125026.719.81513.826.7160026.319.81514.126.3200027.521.214.114.827.5250026.920.114.414.526.9315027.619.915.11527.6400027.321.114.914.827.3500027.420.314.814.827.4630028.317.914.814.928.3800024.416.315.115.124.41000022.615.81515.222.61250018.615.915.215.418.61600016.616.115.315.316.6SPL38.331.827.326.938.3N2.91.50.90.92.9median 24.2median 19.8median 15.1median 15median 24.2Delta2.61.31.31.32.631.831.230.131.326.727.228.228.132.933.529.731.130.931.628.829.429.626.527.731.726.326.824.824.924.625.222.924.123.523.825.827.523.423.923.524.123.32422.823.423.823.423.123.723.122.123.322.521.921.721.922.722.121.421.22220.920.520.821.320.320.219.821.320.519.918.720.62120.117.821.122.621.117.621.322.520.516.920.922.521.116.420.921.720.416.420.421.119.316.320.419.618.51618.418.917.516.116.816.916.516.216.716.616.616.116.416.516.316.216.316.116.115.916.215.915.915.815.932.831.729.732.11.81.61.31.7median 21.1median 20.4median 17.6median 20.92.62.12.92.7hearing rangehide median Fan NoiseHuawei MateBook 13 2020 AMDHuawei MateBook 13 2020 i5
Carga Máxima
 35.3 °C39.3 °C38.8 °C
 32.7 °C37.3 °C37.5 °C
 30.3 °C30 °C32.6 °C
Máximo: 39.3 °C
Médio: 34.9 °C
40.2 °C36.9 °C32.1 °C
38.5 °C34.3 °C32.7 °C
34.5 °C32.9 °C30.8 °C
Máximo: 40.2 °C
Médio: 34.8 °C
alimentação elétrica  41 °C | Temperatura do quarto 22 °C | Fluke t3000FC (calibrated) & Voltcraft IR-260
(±) The average temperature for the upper side under maximal load is 34.9 °C / 95 F, compared to the average of 30.8 °C / 87 F for the devices in the class Subnotebook.
(+) The maximum temperature on the upper side is 39.3 °C / 103 F, compared to the average of 35.9 °C / 97 F, ranging from 21.4 to 59 °C for the class Subnotebook.
(±) The bottom heats up to a maximum of 40.2 °C / 104 F, compared to the average of 39.4 °C / 103 F
(+) In idle usage, the average temperature for the upper side is 28.5 °C / 83 F, compared to the device average of 30.8 °C / 87 F.
(+) The palmrests and touchpad are reaching skin temperature as a maximum (32.6 °C / 90.7 F) and are therefore not hot.
(-) The average temperature of the palmrest area of similar devices was 28.3 °C / 82.9 F (-4.3 °C / -7.8 F).
Consumo de energia
desligadodarklight 0.21 / 0.32 Watt
Ociosodarkmidlight 4.71 / 8.65 / 9.42 Watt
Carga midlight 34.23 / 47.1 Watt
 color bar
Key: min: dark, med: mid, max: light        Metrahit Energy
Huawei MateBook 13 2020 AMD
R5 3500U, Vega 8, WDC PC SN730 SDBPNTY-512G, IPS, 2160x1440, 13"
Huawei MateBook 13 2020 i5
i5-10210U, UHD Graphics 620, WDC PC SN730 SDBPNTY-512G, IPS, 2160x1440, 13"
Apple MacBook Air 2020 i5
i5-1030NG7, Iris Plus Graphics G7 (Ice Lake 64 EU), Apple SSD AP0512, IPS, 2560x1600, 13.3"
Dell XPS 13 9300 i5 FHD
i5-1035G1, UHD Graphics G1 (Ice Lake 32 EU), Toshiba XG6 KXG60ZNV512G, IPS, 1920x1200, 13.4"
Acer Swift 3 SF313-52-52AS
i5-1035G4, Iris Plus Graphics G4 (Ice Lake 48 EU), SK Hynix BC501 HFM512GDJTNG, IPS, 2256x1504, 13.5"
HP EliteBook 735 G6 7KN29EA
R5 PRO 3500U, Vega 8, WDC PC SN520 SDAPNUW-256G, IPS LED, 1920x1080, 13.3"
Average AMD Radeon RX Vega 8 (Ryzen 2000/3000)

Average of class Subnotebook

Power Consumption
-2%
24%
8%
28%
-4%
-7%
-13%
Idle Minimum *
4.71
2.97
37%
2.4
49%
3.4
28%
3
36%
5.6
-19%
5.68 ?(3.7 - 11.5, n=42)
-21%
Idle Average *
8.65
7.5
13%
6.8
21%
6
31%
6.1
29%
8.1
6%
Idle Maximum *
9.42
9.6
-2%
10.5
-11%
10.2
-8%
8.4
11%
9.6
-2%
Load Average *
34.23
38.9
-14%
25.7
25%
36.6
-7%
25.7
25%
34.3
-0%
37.8 ?(24.1 - 55.3, n=42)
-10%
Load Maximum *
47.1
66.7
-42%
30.4
35%
49.3
-5%
27.6
41%
48.6
-3%
Witcher 3 ultra *
24.5

* ... smaller is better

Tempo de Execução da Bateria
WiFi Websurfing (Microsoft Edge 83)
5h 19min
WiFi Websurfing max. Brightness (Microsoft Edge 83)
4h 21min
Big Buck Bunny H.264 1080p
8h 47min
Carga (máximo brilho)
1h 36min
Huawei MateBook 13 2020 AMD
R5 3500U, Vega 8, 41.7 Wh
Huawei MateBook 13 2020 i5
i5-10210U, UHD Graphics 620, 41.7 Wh
Apple MacBook Air 2020 i5
i5-1030NG7, Iris Plus Graphics G7 (Ice Lake 64 EU), 49.9 Wh
Dell XPS 13 9300 i5 FHD
i5-1035G1, UHD Graphics G1 (Ice Lake 32 EU), 52 Wh
Acer Swift 3 SF313-52-52AS
i5-1035G4, Iris Plus Graphics G4 (Ice Lake 48 EU), 54.5 Wh
HP EliteBook 735 G6 7KN29EA
R5 PRO 3500U, Vega 8, 50 Wh
Average of class Subnotebook

Battery Runtime
13%
65%
99%
103%
54%
72%
H.264
527
580
10%
640
21%
866
64%
WiFi v1.3
319
441
38%
618
94%
703
120%
648
103%
492
54%
Load
96
86
-10%
173
80%
205
114%

Pro

+ Carcaça de metal de alta qualidade
+ Bom desempenho do sistema
+ Bons dispositivos de entrada
+ Tela 3:2 brilhante

Contra

- Os componentes são de difícil acesso
- Tela refletiva
- A tela deveria ser calibrada
- USB-C apenas com limitações

Veredicto - O preço tem seu preço

In review: Huawei MateBook 13 (2020) AMD version.
In review: Huawei MateBook 13 (2020) AMD version.

Com o Huawei MateBook 13, os compradores recebem um subportátil muito bom, mesmo com um chipset AMD, que é, acima de tudo, comparativamente barato e já disponível a partir de 749 Euros (~$842). O adaptador USB incluído na caixa é certamente uma consolação fraca para a omissão do MateDock 2.

O iGPU mais potente do chipset Picasso não teve uma grande influência na pontuação, mas pode marcar a diferença entre um jogo que ainda é jogável e um que parece um flipbook, especialmente para jogadores casuais. Também vemos uma pequena vantagem para a versão AMD ao utilizar programas criativos como o Photoshop.

O MateBook 13 com o chipset Ryzen é mais barato, mas os usuários têm de aturar as compensações, sobretudo em termos de duração da bateria.

Por outro lado, se você estiver na estrada com frequência e por muito tempo, você deve pensar duas vezes em não optar pelo modelo Intel, uma vez que a maioria das vezes tem uma pontuação notavelmente melhor em termos de duração da bateria. Qualquer MateBook que você escolher, ambas as variantes de chip estão alojadas em uma carcaça metálica de alta qualidade, que foi equipada com dispositivos de entrada decentes. Aqueles que também possuem um smartphone Huawei meio atualizado obterão um recurso adicional útil com o Huawei Share.

Huawei MateBook 13 2020 AMD - 06/29/2020 v7 (old)
Daniel Schmidt

Acabamento
84 / 98 → 86%
Teclado
84%
Mouse
86%
Conectividade
45 / 75 → 60%
Peso
71 / 20-75 → 93%
Bateria
72%
Pantalha
83%
Desempenho do jogos
51 / 78 → 66%
Desempenho da aplicação
83 / 85 → 97%
Temperatura
91%
Ruído
97%
Audio
65 / 91 → 71%
Camera
35 / 85 → 41%
Médio
73%
84%
Subnotebook - Médio equilibrado

Price comparison

Please share our article, every link counts!
Mail Logo
> Análises e revisões de portáteis e celulares > Análises > Análises > Breve Análise do Huawei MateBook 13 (2020) - Um portátil Ryzen nem sempre é a melhor opção
Daniel Schmidt, 2020-07- 3 (Update: 2020-07- 4)
